We have a special range of curly cords that are used for wiring the push button & toggle switch controls etc, on the car’s (or boat’s) steering wheel to switch relays. For Gear Change, Nitrous, etc Most have high quality Black Polyurethane jackets. These cords are typically 300 mm long (Compressed coil length) Shorter and/or Longer cords also available. Several other cable types are also available as well.
Please email sales@proconnect.com.au for prices. Cord Details:
Standard cords are 300mm coil, with 150mm straight tails.
other lengths made to order.
| PRO-1TP-0.75FSCN-PU-PU-300-150 | 1 Twisted Pair (2 Cores) 0.75mm² Foil Screened and drain wire. 5.5mm Nominal O.D. Coil length 300mm +150mm Straight Tails |
$76.50 | Click here to order |
| PRO-2TP0.2SCN-PU-300-150 | 4 Core (2 twisted pairs) 0.2mm² Double Screened with Foil and Spiral Lapp 6.2mm Nominal O.D. Coil length 300mm +150mm Straight Tails |
$88.00 | Click here to order |
| PRO-8C0.1FSCN-PU2-300-150 | 8 Core 0.1mm² Foil Screen and drain wire. 5.6mm Nominal O.D. Coil length 300mm +150mm Straight Tails |
$91.50 |
Slightly smaller & lighter version of above:
| PRO-8C0.09FSCN-PU-300-150 | 8 Core 0.09mm Foil Screen and drain wire. 4.0mm Nominal O.D. Compressed Coil length 300mm +150mm Straight Tails |
$91.50 | Click here to order |
| PRO-12C0.08FSCN-PU-300-150 | 12 Core 0.1mm² Foil Screen and drain wire. 6.2mm Nominal O.D. Coil length 300mm +150mm Straight Tails |
$104.25 | Click here to order |
| PRO-25C0.08FSCN-PU-300-150 | 25 Core 0.08mm² Foil Screen and drain wire. 8mm Nominal O.D. Coil length 300mm +150mm Straight Tails |
$135.00 | Click here to order |
Unless specifically indicated, all curly cords are supplied UNTERMINATED.
Connectors and accessories include delivery when ordered with cords, otherwise delivery fee will apply.
| PRO-CB16-8FIP | 8 Pole Female Inline Plug | $12.00 | Click here to add to order | |
| Assembly | Assembly charge to fit above connector to cord |
$20.00 | Click here to add to order | |
| PRO-CB16-8MPS | 8 Pole Male Panel Socket | $12.00 | Click here to add to order |
Similar to above picture, but now with 15 pins.
| 15 pole 20mm connectors | ||||
| PRO-CB20-15FIP | 15 Pole Female Inline Plug | $22.00 | Click here to add to order | |
| Assembly | Assembly charge to fit above connector to cord |
$25.00 | Click here to add to order | |
| PRO-CB20-15MPS | 15 Pole Male Panel Socket | $20.00 | Click here to add to order |
| Part Number | Description | Price each | Ordering Link |
| SW-12MMR | Switch Illuminated 12mm Metal Momentary Red | $15.00 | Click here to order |
Hi. Can you please advise the price of the 7 core and 8 core Steering Wheel Curly Cords? Thanks.
Hi Ian,
Yep Sure thing.
I’ll shoot you an email now…
Cheers
Paul.
I run a steering wheel curly and have just added some more buttons so need a price on your 8 core cable (300 mm long) and the price of those neat 8 wire connect/disconnectors
And post to South Australia 5042 please – are you with Paypal?
Hi Lloyd,
Thanks for your inquiry.
I’ll shoot you an email shortly.
We don’t currently use Paypal. But we do take credit card payments. I will elaborate in the email.
All the best…
Paul.
Hi,
as a lack of any other finds on the internet I’ll just ask here..
I’m in need of (several) curled cords for my simracing setup (custom built steering wheel). I’d need about 5-8 cables, curled 300mm length (compressed) with preferrably 21+ pins (16 of them can be unshielded, but I’d in best circumstances need 4 shielded wires that are suitable for USB data transmission. Alternatively please provide me an offer for a simple 16 (or 19) wires unshielded cable.
I don’t know about international shipping or pricing so I’d like to get an offer on that. Shipping would be to Austria (Europe).
If the pricing is acceptable for us I probably could organize a mass order through our community with 25+ cables..
regards,
Bernhard
Hi Bernhard,
In theory we could make a custom cable to make these cords…but in practice the minimum order of cable would be too high. (I would need to confirm, but we would probably need to make 200+ cords to get it made.)
Wo what we need to do is look at what we have that might be close to your spec.
I’ll look into it, and email you shortly.
All the best…
Paul.
Hello Sales
I am needing an 8 core 400mm curled length cable for a steering wheel , with a male and female jack plug cable to be 1 common and the rest switched , probably good to be shielded , the wheel is on a disconnect hub,
Can you help please ?
THanks John
Dynotuning
Hi John,
Got your comment and email.
Will reply via email shortly.
Best regards
Paul.
Hi,
I’m after a quote on 2 x 8 core curly cord delivered to Melbourne.
Cheers
Hi Paul,
I have several of the 8 core ones here in stock,
I’ll shoot you a price now.
Best regards
Paul.
what it the AWG of PRO-8C0.09FSCN-PU-300-150
thanks
Hi Mario,
At times I find AWG is a little imprecise, and different charts may list is as slightly different numbers.
This one is 19/.08 (19 Strands of 0.08mm diameter) which comes out at 0.09mm² (Square mm) which is ~28AWG. (Depending on the specific chart you are using)
Does that work for you?
Please let me know if you prefer something different.
Best regards
Paul.
